Soshine S1-Max 4 slots 18650 Li-ion battery charger, battery charger for lithium-ion batteries

Soshine S1-Max 4 slots 18650 Li-ion battery charger, battery charger for lithium-ion batteries

  • Batteries Supported
    18650/18650(protected)/17650/18500/17500 Lithium-Ion Batteries
  • Color
    Black
  • Used For
    3.7V Lithium-ion Batteries
  • Feature
    4-slot Charger
  • Size
    125*67*35mm
  • Battery Model
    18650, 18500, 17500
  • Applicable Battery
    Any Brand/Capacity/Power
  • Shipment
    DHL, UPS, TNT, FedEx, Sweden Post, EUB
  • Payment
    Paypal, Western Union, Bank Transfer
  • Lead Time
    Within 2-5 Days
  • SKU
    PW1047
  • Skype
    Power4world
  • Place of Origin
    China
  • Brand Name
    Soshine
  • Certification
    CE, RoHS
  • Model Number
    SC-S1 max III
  • Minimum Order Quantity
    100pcs
  • Price
    13
  • Packaging Details
    retail color box
  • Delivery Time
    within 2 to 5 days
  • Payment Terms
    Paypal, Western Union, T/T
  • Supply Ability
    1000000pcs

Soshine S1-Max 4 slots 18650 Li-ion battery charger, battery charger for lithium-ion batteries

Soshine S1-Max 4 slots 18650 Li-ion battery charger, battery charger for lithium-ion batteries

Model: SC-S1 max III



Quick charge
This charger is an intelligent charger especially designed to charge rechargeable 1-4pcs 18650/18650(protected)/17650/18500/17500 Lithium-Ion batteries



Specification:

Adapter:

Input: AC100-24V 50/60Hz

Output: DC12V 1800mA

DC car adapter: 12V

DC out: 4.2V 1x1000mA, 2x1000mA, 3x 1000mA, 4x1000mA

Trickle charge: 50mA

Using an adapter that does not meet these specifications could damage the charger or the adapter.



Feature:

- End-of-charge voltage detection assures the safe and full charge any time
- Short-circuit protection
- Over voltage cut-off protection ------ prevents damage to your battery due to over voltage
- Complete individual channels ------- convenience; prevent batteries charge each other
- Charge Method :CC/CV -------------- charge battery fully and quickly
- Reverse polarity protection ---------- prevent damage to your battery and charger
- Time control  ---------------------------- 4 individual clocks, after charge 8 hour, the power cut down

- Battery reset ---------------------------- make short circuit protection battery to reset



4 LED indicate:
Red on ------------------------------------ Battery Charging

Green flash ------------------------------ Charge 80%-90% complete
Green on --------------------------------- Charge 90%-100% complete
Turn off ----------------------------------- Stand by without battery in compartment
                                                              Loose connections (replace battery);
                                                              Polarity reversed (load the battery into charger in right side)
                                                              Low voltage less than 2.0V
Red-Green flash (after 5min) ---------- Non rechargeable Li-ion battery like Lithium,Ni-MH ,Ni-Cd, Alkaline
                                                              Li-ion battery--Low voltage between 2.0V-3.0V
                                                              Temperature >60 degree



Charge time:



Channel

Type

Model

Capacity

Charging time(H)



(mAh)

1PCS

2PCS

3PCS

4PCS



I,II III,IV

Li-ion

18500

1400

1.4

1.4

1.4

1.4



Li-ion

17500

1200

1.2

1.2

1.2

1.2



Li-ion

17650

1400

1.4

1.4

1.4

1.4



Li-ion

18650

1800

1.8

1.8

1.8

1.8



Li-ion

18650 J/P

2000

2.0

2.0

2.0

2.0



Li-ion

18650 J/P

2200

2.2

2.0

2.2

2.2



Li-ion

18650J

(protected)

2800

2.7

2.7

2.7

2.7



This chart is for your reference only .The actually time may short than the chart





Instructions for use:

-Insert the rechargeable Li-ion battery into the battery compartment.

-Make correct contact for polarity (+ and -) according to the sign in the battery compartment.



When using AC adapter:

Connect the supplied AC adapters barrel plug into jack on the back of the charger. Plug the AC adapter into any available 100-240VAC outlet.



When using in vehicle-DC car adapter:

Connect the supplied DC car adapters barrel plug into the charges DC input jack. Plug the large end of the cord into the 12V car lighter power port.

-The Red LED will glow to indicate the proper charging. After the battery is fully charged, the red LED will turn off and green LED will light on indicating the charged battery is ready for use.

-Unplug the charger and remove from the charger when not in use.



Power supply:

Protect the power supply cable for the adaptor against the risk of being trodden on, pinched or folded, particularly near the sockets and the connection with the device.

Keep out of the reach of children or pet.

To disconnect the power supply cable, pull on the plug and not on the cord.

If the power supply cable is damaged, stop using the device immediately.



Tips:

It is normal for batteries to warm up while charging. They will cool down after they are charged.



Not charging all the way?

1 Gently rubs battery ends with a clean pencil eraser or cloth to remove any residue

2 Loose connections between battery and charger replace battery into the battery compartment; turn the battery until LED from green turn red.

3 Polarity reversed; load the battery into charger in right side until LED from green turn red.



Warning:

To avoid personal injury and property damage from, but not limited to, the risk of electric shock or fire:

Charge only rechargeable Lithium-Ion batteries. Charging any other types of batteries may cause them to leak, rupture or explode.

Do not open battery, dispose of in fire, put in backwards, mix with used or other battery types or short circuit-may ignited, explode, leak or get hot injury

Use the charger only in dry locations. Keep away from rain, snow or excessive moisture.

Do not operate the charger if damaged

Do not disassemble, modify any part of the charger ,or attempt to use the chargers as power source

Always unplug the charger from outlet before attempting maintenance or cleaning,

This charger is not a toy and should not be used by children or infirm persons without adequate training or supervision.



Approve: adaptor UL  CE  EK PSE SAA

Material: ABS ROHS



One year warranty

This Soshine product is warranted only to the original purchaser upon presentation of proof of purchase, to be free from defects in materials and workmanship for one year from date of original purchase provided that no other repairs, alterations or modifications had been attempted by unauthorized personnel. Not applicable to damage caused by normal wear and tear or misuse. Repair or replace of charger at Soshine option. For more information, please contact your nearest Soshine sales.



Quality Guarantee:
Power-Wholesale Website is committed to providing you with authentic Soshine battery charger. Every charger sold was tested strcitly and of the highest quality.

  • We only sell authentic Li-Ion batteries and chargers.

  • Every item is well inspected.



Price:

  • We totally understand the price is crucial to a wholesaler, so we will do our best to maximize your profits.

  • We won’t ensure you our price is lowest but we ensure you what you paid is the price for authentic battery and charger.



Detail Photos Show:

Soshine S1-Max 4 slots 18650 Li-ion battery charger, battery charger for lithium-ion batteries 0Soshine S1-Max 4 slots 18650 Li-ion battery charger, battery charger for lithium-ion batteries 1

To know more about Soshine S1-Max 18650 battery charger, please check the official Data Sheet with us by following way:
