18650/RCR123 16340 Li-ion Battery Charger
Model:SC-S1 mix III
The intelligent charger is especially designed to charge rechargeable 1-2 pcs 18650 /17650/18500/17500 and 1-2pcs 16340/17335/15266/14250/14430/14500/10440 Lithium-Ion batteries
Technical characteristics
Adapter:
- Input: AC adapter 100-240VAC,50/60Hz
- Output:12VDC - 1500mA
- DC car adapter :12V
Using an adapter that does not meet these specifications could damage the charger or the adaptor
Charger:
- Li-ion 18650 18500 - charging current =1000mA*1, 1000mA*2
- Li-ion 16340 18650 18500 10440 17335 RCR123- charging current =300mA*1, 300mA*2
- End-of-charge voltage detection assures the safe and full charge any time
- Short-circuit protection
- Over voltage cut-off protection --- prevents damage to your battery due to over voltage(4.3V)
- Complete individual channels ------ convenience; prevent batteries charge each other
- Charge Method :CC/CV --------------charge battery fully and quickly
- Reverse polarity protection -------- prevent damage to your battery and charger
- Time control ------------------------- 4 individual clocks,after charge 8 hour, the power cut down
- Temperature control ---------------- temperature >60 degree, the power cut down
- Battery reset---------------------------make short circuit protection battery to reset
4 LED indicate:
Red on ------------------------------------Battery Charging
Green flash ------------------------------Charge 80%-90% complete
Green on ---------------------------------Charge 90%-100% complete
Turn off -----------------------------------Stand by without battery in compartment
Loose connections (replace battery);
Polarity reversed (load the battery into charger in right side)
Low voltage less than 2V
Red-Green flash (after 5min) ----------Non rechargeable Li-ion battery like Lithium,Ni-MH ,Ni-Cd, Alkaline
Li-ion battery--Low voltage between 2-3V
Temperature >60 degree
Charge time:
|
Channel
|
Type
|
Model
|
Capacity
|
Charging time(H)
|
(mAh)
|
1PCS
|
1PCS
|
1PCS
|
2PCS
|
2PCS
|
2PCS
|
I,II
|
Li-ion
|
10440
|
350
|
1.4
|
______
|
1.4
|
______
|
1.4
|
1.4
|
Li-ion
|
14250
|
250
|
1
|
______
|
1
|
______
|
1
|
1
|
Li-ion
|
14430
|
700
|
2.8
|
______
|
2.8
|
______
|
2.8
|
2.8
|
Li-ion
|
14500
|
750
|
3.0
|
______
|
3.0
|
______
|
3.0
|
3.0
|
Li-ion
|
15266J/P
|
300
|
1.2
|
______
|
1.2
|
______
|
1.2
|
1.2
|
Li-ion
|
16340J/P
|
700
|
2.8
|
______
|
2.8
|
______
|
2.8
|
2.8
|
Li-ion
|
17335J/P
|
650
|
2.6
|
______
|
2.6
|
______
|
2.6
|
2.6
|
III,IV
|
Li-ion
|
17500
|
1200
|
______
|
1.4
|
1.4
|
1.4
|
_____
|
1.4
|
Li-ion
|
17670
|
1400
|
______
|
1.7
|
1.7
|
1.7
|
_____
|
1.7
|
Li-ion
|
18500
|
1400
|
______
|
1.7
|
1.7
|
1.7
|
_____
|
1.7
|
Li-ion
|
18650
|
2200
|
______
|
2.6
|
2.6
|
2.6
|
_____
|
2.6
|
Li-ion
|
18670(with PCB)
|
2800
|
______
|
3.4
|
3.4
|
3.4
|
_____
|
3.4
|
This chart is for your reference only .The actual time may shorter than that the chart shows.
|
Instructions for use:
-Insert the rechargeable Li-ion battery into the battery compartment
-Make correct contact for polarity (+ and -) according to the sign in the battery compartment
When using AC adaptor:
Connect the supplied AC adaptors barrel plug into jack on the back of the charger. Plug the AC adaptor into any available 100-240VAC outlet.
When using in a vehicle-DC car adaptor:
Connect the supplied DC car adaptors barrel plug into the charges DC input jack. Plug the large end of the cord into the 12V car lighter power port
-The Red LED will glow to indicate the proper charging. After the battery is fully charged, the red LED will turn off and green LED will light on indicating the charged battery is ready for use.
-Unplug the charger and remove from the charger when not in use.
Power supply:
Protect the power supply cable for the adaptor against the risk of being trodden on, pinched or folded, particularly near the sockets and the connection with the device.
Keep out of the reach of children or pet.
To disconnect the power supply cable, pull on the plug and not on the cord.
If the power supply cable is damaged, stop using the device immediately.
Tips:
It is normal for batteries to warm up while charging. They will cool down after they are charged.
Store batteries in a cool dry place at room temperature.
Rechargeable batteries gradually lose power when store. If they are not used for more than one year, charge the battery complete. but cannot use ,the battery may damaged. Replace a new battery.
Not charging all the way?
1.Gently rub battery ends with a clean pencil eraser or cloth to remove any residue
2.Loose connections between battery and charger ,replace battery into the battery compartment, turn the battery until LED from green turn red.
3.Polarity reversed,load the battery into charger in right side until LED from green turn red.
Warning:
To avoid personal injury and property damage from, but not limited to, the risk of electric shock or fire:
Charge only rechargeable Lithium-Ion batteries. Charging any other types of batteries may cause them to leak, rupture or explode.
Do not open battery, dispose of in fire, put in backwards ,mix with used or other battery types or short circuit-may ignite, explode, leak or get hot injury
Use the charger only in dry locations. Keep away from rain, snow or excessive moisture.
Do not operate the charger if damaged
Do not disassemble, modify any part of the charger ,or attempt to use the chargers as power source
Always unplug the charger from outlet before attempting maintenance or cleaning,
This charger is not a toy and should not be used by children or infirm persons without adequate training or supervision.
Approve: adaptor UL CE CCC EK PSE SAA
Material: ABS ROHS
One year warranty:
This Soshine product is warranted only to the original purchaser upon presentation of proof of purchase, to be free from defects in materials and workmanship for one year from date of original purchase provided that no other repairs, alterations or modifications had been attempted by unauthorized personnel. Not applicable to damage caused by normal wear and tear or misuse. Repair or replacement of charger at Soshine option. For more information, please contact your nearest Soshine sales office.
