Nominal Specifications:
Item | Specification |
Model Name | Sanyo UR18650RX |
Capacity |
Min. 1950mAh Typ.2000mAh |
Nominal Voltage | 3.7V |
Charge Method |
CC-CV, Standard charge: 0.5-1C to 4.2V then CV 4.2V |
Charging Current | Standard 30mA |
Charging Voltage | 4.20V |
Max. Discharge Current | 22A |
Discharge Cut-off Voltage | 2.75V |
Temperature |
Charge: 0 to +45°C Storage: -20 to +50°C |
Dimension (max.dimension with tube) |
18.20mm (D) 65.00mm (H) |
Weight (max.) | 45g |
Internal resistance | ≤22 mΩ |
Cycle Times | 500(≥60% C5mAh) |
Features:
High drain density cell with 22A continuous discharge rate.
Genuine Sanyo Battery cells
Long, stable power with a flat discharge rate.
Direct factory price and short lead time
Product Advantages:
1) Green product
2) Long standby time
3) 6 months warranty
4) Excellent safety performance
5) Excellent storage performance and low self-discharge rate
6) Short circuit testing passed
7) Overcharge testing passed
8) Over discharge testing passed
Applications:
Power tools
Electric Bicycle
E-cigarette
Robotics
Other electronic devices:
Portable equipment: POS, Portable printer, handset.
Medical instrument; B ultrasound, Ecg monitoring instrument electric pulmotor
Consumer electronics; PDA,MID, laptop, emergency light power source
Electric power tool e-bicycle
Industrial and commercial instrument; light power meter Gas testing instruments fusion splicer flaw detector
Electric toy; RC car/ boat/helicopter
Cautions:
1. When using the application equipped with the battery, refer to the user’s manual before usage.
2. Please read the specific charger manual before charging.
3. Charge time should not be longer than specified inthe manual.
4. When the cell is not charged after long exposure to the charger, discontinue charging.
5. Battery must be charged at operating temperature range 0 ~ 45°C.
6. Battery must be discharged at operating temperature range -20 ~ 60°C.
7. Please check the positive(+) and negative(-) direction before packing.
8. When a lead plate or wire is connected to the cellfor packing, check out insulation not to short-circuit.
9. Battery must be stored separately.
10.Battery must be stored in a dry area with low temperature for long-term storage.
11.Do not place the battery in direct sunlight or heat.
12.Do not use the battery in high static energy environment where the protection device can be damaged.
13.When rust or smell is detected on first use, please return the product to the seller immediately.
14.The battery must be away from children or pets
15.When cell life span shortens after long usage, please exchange to new cells.
Quality Guarantee:
www.eleteks.com is committed to providing you with authentic 18650 lithium-ion batteries. Every battery sold was tested strcitly and of the highest quality.
We only sell authentic Li-Ion batteries.
The authentic 18650 batteries are well inspected.
Price:
We totally understand the price is crucial to a wholesaler, so we will do our best to maximize your profits.
We won’t ensure you our price is lowest but we ensure you what you paid is the price for authentic rechargeable Li-ion batteries.
Detail Photos Show:
To know more about Sanyo UR18650RX 2050mAh / 2100mAh rechargeable 18650 lithium-ion battery, please check the official Data Sheet with us by following way:
